Accucraft Trains is proud to announce narrow gauge
American 4-4-0 in 1:20.3 scale and 45mm gauge. Based
on South Pacific Coast #3 prototype, the model will be handcrafted in
live steam. Models are
constructed from brass and stainless steel.
All Accucraft
Trains models are designed and built to exacting
standards from carefully researched plans and
prototype measurements. We hand-craft every detail
part from brass and steel. Every effort is made to
assure quality of each part.
|
|
SPECIFICATIONS |
|
|
|
| Scale/Gauge |
1:20.3 Scale/ 45mm
Gauge |
| Minimum Radius |
1.2 M, 48 in. |
| Valve Gear |
Simplified
Stephenson |
| Valves |
Slide Valves -
D-Valve |
| Reversing |
Johnson bar
controlled links |
| Fuel |
Butane |
| Boiler |
Single Flue |
| Water Capacity |
300 ml |
| Working Pressure |
40-60 PSI |
| Fittings |
Safety valve, Water
filler valve, Throttle, Steam pressure gauge |
| (All specifications and designs are subject to change without
notice) |
|
|
|
ORDER INFORMATION |
|
|
|
| AC77-720 |
AMERICAN 4-4-0 LS
- UNLETTERED BLACK |
| AC77-721 |
AMERICAN 4-4-0 LS - SOUTH PACIFIC
COAST RED #9 |
| AC77-722 |
AMERICAN 4-4-0 LS - SOUTH PACIFIC
COAST GREEN #3 |
| AC77-723 |
AMERICAN 4-4-0 LS
- N.C.N.G. GRASS VALLEY #1 |
| AC77-724 |
AMERICAN 4-4-0 LS
- D&RG COL. BOONE #101 |
|
|
